Product Information
Standard Configuration:
| Weight (approximate) |
Camera head and cable: 300g / 0.66lbs Video Console: 544g / 1.2lbs |
| Camera Dimensions (approximate) |
Length: 7.7cm / 3.03in Width: 4.0cm / 1.57in Height: 5.3cm / 2.08in |
| Console Dimensions (approximate) |
Length: 16.0cm / 6.3in Width: 4.0cm / 1.57in Height: 4.0cm / 1.57in |
| Power Source | External AC/DC switching power supply Rating (AC): 100-240 VAC, 1.2A, @ 50 – 60 Hz Rating (DC): 12 VDC, 2.5A |
| Protection against ingress of water |
Camera head and cable: IP67 Video Console: IP40 |
| Mounting | C-mount universal coupler |
| Image Sensor | CMOS sensor, 2.12 M active pixels |
| Console Outputs | 1x HD-SDI 1x HDMI (Type A Connector) |
| Display Formats | 1280×720 1920×1080 |
| Operating Conditions | Temperature: 0°C to +40°C (+32°F to +104°F) Relative Humidity: 20% to 90% noncondensing |
