Product Information
Standard Configuration:
- 2x Doppler Probe
- 1x UC Probe
- 1x Event Mark Jack
- 2x Print Paper
- 3x Probe Belt
- 1x Power Adaptor & Cord
- 2x Probe Holder
- 1x Ultrasound Gel(250ml)
| Functional Characteristics | |
| FHR | |
| Method | Pulsed Doppler (Twin) |
| Detection Technique | Autocorrelation |
| Ultrasound Frequency | 0.985MHz |
| FHR Range | 30 ~ 240 / 50 ~ 210bpm ±2% |
| Ultrasound Intensity | 10mW/cm² or less |
| FHR Resolution | 1bpm |
| FM | |
| Auto Twin Detection | |
| Display | |
| Channel | 3(FHR 1, FHR 2, UC) |
| Type | 7″ TFT Color LCD (L)
7 Segment LED (E) |
| UC(TOCO) | |
| Frequency Response | DC ~ 0.5Hz |
| Measurement Range | 0 ~ 100units |
| External Type | |
| Reference(Zero) Control | |
| Printer | |
| Paper Type | Z-fold, 150mm(W), 13.5m(Length) |
| Printer Type | Thermal Array |
| Print Speed | 1, 2, 3cm/min, 10cm/min(Trend) |
| Paper Feeding | |
| Function | |
| Auto Print | Off, 10, 20, 30, 40, 50, 60min |
| FHR 2 Offset | |
| Zoom-in | |
| FM Graph Print | |
| Event Mark | |
| Auto FHR Trend Interpretation | |
| CCV(Cross Channel Verification) | |
| Multi-language (L) | |
| Quick Guide (L) | |
| Power On Self-Test (L) | |
| Patient Name & ID (L) |
