Product Information

Standard Configuration:

Dimensions 14” x 35” x 48” (5.5cm x 13.5cm x 18.9 Cm”)
Weight 9.8 Lbs. (21.5 Kg)
Generator Solid-State
Frequency 391 Cut, 562 Coag

391 Bipolar

Cooling System Convection, Fan
Independent Output Yes
Power Setting Display Yes
Visual (Alerts) Yes
Audible (Alerts) 2 Tones
Volume Control (Signals) Yes
Power Needed, Vac (Energy) 90-127, 198-253″
Bandwidth (Outputs) 2
Footswitch Yes
Bipolar System Yes
Monopolar Cut (Blend) Coagulate
Max. Energy Output (At Rated Ohms) (Systems) More than 250 Watts 300 Max Peak Voltage: 820 Pure
Max. Energy Output (At Rated Ohms) (Systems) Up to 150 Watts 80 Max Peak Voltage: 6,350 spray
Bipolar (Macro, Micro)
Max. Energy Output (At Rated Ohms) (Systems) Up to 150 Watts 90 Max Peak Voltage: 610 Macro
Max. Energy Output (At Rated Ohms) (Systems) Up to 50 Watts 50 Max Peak Voltage: 170 Micro
