| Therapy |
Adult defibrillation peaks current: 32A (150J nominal) into a 50 ohm load. Pediatric defibrillation (with optional Infant/Child Key installed): 19A (50J nominal) into a 50 ohm load. |
| Battery |
Standby life (after insertion): Typically 4 years when stored and maintained according to directions provided in Owner’s Manual. |
| Waveform |
Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance. |
| Protocol |
Device Protocol follows preconfigured settings. Defibrillation and CPR protocol can be customized using Heart Start Configure software. |
| Quick Shock |
Able to deliver a shock after the end of a CPR interval, typically in eight seconds. |
| Physical Requirements |
|
| Size |
2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W |
| Weight |
With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg) |
| Environmental |
|
| Temperature |
Operating/Standby:32° – 122° F (0° – 50° C) |
